High-Speed Rolling Doors | Energy-Efficient Automated Solutions for Warehouses & Factories
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | MRJH |
| Certification: | ISO、CE、UL |
| Model Number: | Fast rolling door |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Delivery Time: | 7-15 days |
|
Detail Information |
|||
| Custom Made: | Support | Official Website: | Www.ffu-cleanroom.com |
|---|---|---|---|
Product Description
High-Speed Rolling Doors | Energy-Efficient Automated Solutions for Warehouses & Factories
High-visibility high-speed roll-up door with airtight seals and 1.2mm PVC window. Adjustable speeds (0.6-2.5m/s), ideal for food processing, pharmaceuticals, and sterile logistics. Meets DIN 75200 standards.
| Parameter Name | Value |
|---|---|
| Door Structure | Precision-crafted stainless steel frame with anti-slip, wear-resistant surface finish |
| Drive System | 220V/50Hz electric motor, 2.2KW power output |
| Safety System | Dual safety photoelectric sensors at door base; auto-reverse function upon obstruction |
| Operating Speed | Opening: 0.6-2.5 m/s (adjustable) / Closing: 0.8-2.0 m/s (adjustable) |
| Door Curtain Material | French industrial polyester fiber with dual PVC coating (0.8mm thickness) |
| Wind Resistance | German DIN-standard high-strength aluminum alloy wind bars for up to 12 Beaufort resistance |
| Transparent Window | 1.2mm thick horizontal PVC strip for visibility during entry/exit |
| Sealing System | Weighted air-sealed bottom cloth + rubber side seals (insect/dust-proof) |
| Control Mode | Manual switch + radar motion sensor activation |
| Limit Switch | Precision travel locator for one-time positioning accuracy |
Application Scenarios
Compliance & Certifications
-
Material fire resistance: DIN 75200
-
Safety sensors: ISO 13849-1 PLc
-
Operational temperature range: -30°C to +70°C
Notes
-
Customizable curtain colors per client-provided RAL samples.
-
Optional upgrades: Thermal insulation layers, RFID access integration.
FAQs
-
How do your doors withstand frequent forklift impacts?
Our reinforced steel tracks and anti-collision technology ensure minimal damage from accidental collisions, reducing downtime and repair costs. -
Can these doors maintain temperature in extreme climates?
Yes! Built with 50mm insulated PVC panels and airtight seals, they maintain ±1°C temperature stability in -20°C to +50°C environments. -
What if the power fails during operation?
Our emergency battery backup system ensures seamless operation for 4+ hours, preventing workflow disruptions.
