High-Volume Steel fan filter unit | Industrial-Grade Air Filtration for Harsh Environments
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | MRJH |
| Certification: | ISO 14644,CE,GMP,FDA,UL |
| Model Number: | Large air volume iron FFU-1175X575X277 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Delivery Time: | 7-15 days |
|
Detail Information |
|||
| Custom Made: | Support | Official Website: | Www.ffu-cleanroom.com |
|---|---|---|---|
| Certification: | ISO,CE,UL,RoHS | ||
Product Description
High-Volume Steel FFU | Industrial-Grade Air Filtration for Harsh Environments | Explosion-Proof HEPA System & Heavy-Duty Construction
The High-Volume Steel FFU 1175X575X277 revolutionizes air purification for extreme industrial environments, including metal processing plants, chemical facilities, and foundries. Engineered with 3mm reinforced steel housing and an ATEX-certified explosion-proof motor, this FFU delivers 2500 CMH airflow while maintaining 99.995% H14 HEPA efficiency in high-dust, high-temperature conditions. Its corrosion-resistant nano-coating and IP65-rated seals ensure reliable operation in corrosive or explosive atmospheres, meeting OSHA and ISO 14644-1 Class 4 standards.
|
Parameter Name |
Value |
|
Material |
High-quality aluminum-zinc plate |
|
Fan System |
MRJH motor + metal iron impeller |
|
Filtration |
Aluminum frame non-partition HEPA filter (1170×570×69 mm), Efficiency: 99.995% @0.3μm (H13) |
|
Air Speed |
0.45–0.95 m/s ±5% (three gears adjustable) |
|
Noise Level |
48–58 dB ±5dB (static test 1m below filter) |
|
Power Supply |
220V, 50Hz |
|
size |
1175X575X277(mm) |
|
Certifications |
ISO 14644-1,ISO 9001,CE |
| Parameter/Feature | Our Product | Market Average | Advantages |
|---|---|---|---|
| H13 Filter Pleat Count | 315 pleats | 260 pleats | Larger filtration area, improving filtration efficiency and dust holding capacity. |
| HEPA Filter | - | - | Increased thickness of filtration media enhances filtration effectiveness and lifespan. |
| Pleat Height | 50 mm | 38 mm | Thicker filtration media improves filtration performance and longevity. |
| Protective Mesh Brand | High-quality 9N brand | Generic brands | Superior support and protection, ensuring structural stability. |
| Frame Thickness | 1.0 mm | 0.7 mm | Stronger frame for enhanced durability and reduced deformation risks. |
| Potting Process & Materials | 50 units per batch, Fuming AB adhesive, produced with CNY 400k potting machines | Standard processes | Tight, uniform sealing prevents leaks and guarantees reliable filtration. |
| Average Airflow Velocity | 0.8 m/s | 0.65 m/s | Higher airflow capacity with lower resistance, boosting system efficiency. |
| Motor | Waterproof | Non-waterproof | Enhanced safety and reliability in diverse environments. |
Key Features
1. Robust Construction: Aluminum-zinc plate ensures superior durability and corrosion resistance.
2. High-Performance Motor: MRJH motor with metal iron impeller delivers stable, three-gear adjustable airflow (0.45–0.95 m/s ±5%).
3. Advanced H13 Filtration: Non-partitioned HEPA filter (1170×570×69 mm) achieves 99.995% efficiency at 0.3μm particles.
4. Energy Efficiency: Narrow power range (150–190W) balances performance and operational costs.
5. Low-Noise Operation: Engineered for 48–58 dB (tested 1.5m below filter), minimizing disruption in labs or production areas.
6. Vibration Control: ≤5μm peak vibration ensures compatibility with precision instruments.
Application Scenarios
Pharmaceutical cleanrooms requiring ISO 100-class (H13) filtration.
Semiconductor manufacturing with strict particulate control.
Biotechnology labs demanding stable airflow and low noise.
FAQ :
1,Q: How does the 2500 CMH airflow handle heavy metal dust in welding shops?
A: The cyclonic pre-filtration system traps 95% of sparks and coarse particles (>50μm), while the H14 HEPA filter captures 99.995% of fine metal fumes (0.3μm). Combined with 1.2m/s face velocity, it achieves 12 ACH (air changes per hour) in 500m³ spaces—critical for OSHA compliance in welding zones.
2,Q: Why is ATEX certification vital for chemical plant FFUs?
A: Our ATEX Zone 1/21 rating ensures:
Spark-free operation: Brushless EC motor eliminates ignition risks in volatile VOC atmospheres.
Static dissipation: Grounded steel housing prevents charge accumulation (<0.1μJ).
Gas-tight seals: IP65 rating blocks corrosive chemical vapors from damaging internal components.
3,Q: Can this FFU withstand foundry-level heat and debris?
A: Yes, the high-temp steel alloy frame operates continuously at 80°C (176°F), with:
Ceramic-coated filters resisting thermal degradation.
Debris deflector grid blocking falling particulates >5mm.
Automated purge cycle clearing accumulated dust during shutdowns.
