AC FFU 1175X575X215 Industrial Fan Filter Unit | HEPA Air Purification for Cleanrooms | Energy-Saving & Low Noise
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | MRJH |
| Certification: | ISO 14644,CE,GMP,FDA,UL |
| Model Number: | AC FFU 575X575X215 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Delivery Time: | 7-15 days |
|
Detail Information |
|||
| Custom Made: | Support | Official Website: | Www.ffu-cleanroom.com |
|---|---|---|---|
| Certification: | ISO,CE,UL,RoHS | ||
Product Description
AC FFU 1175X575X215 Industrial Fan Filter Unit | HEPA Air Purification for Cleanrooms | Energy-Saving & Low Noise
The FFU (Fan Filter Unit) is a high-performance air purification system engineered for ISO 14644-1 compliant cleanroom environments. Designed for industrial and laboratory use, it features a high-quality aluminum-zinc plate casing, an MRJH® large air volume low-noise motor with metal impeller, and a non-partition HEPA filter for exceptional particulate control. With three-speed adjustable airflow, energy-efficient operation, and precision vibration management, it guarantees reliable air quality in critical applications.
|
Parameter Name |
Value |
|
Material |
High-quality aluminum-zinc plate |
|
Fan System |
MRJH motor + metal impeller |
|
Filtration |
Aluminum frame HEPA filter (1170×570×69), Efficiency: 99.995% @0.3μm (H13) |
|
Air Speed |
0.45–0.95 m/s ±5% (three-speed adjustable) |
|
Noise Level |
48–58 dB ±5 dB (static test 1.5m below HEPA) |
|
Power Supply |
220V/50Hz, Rated Power: 150W–190W ±5W |
|
Vibration |
≤5μm peak |
|
size |
1175X575X215 (mm) |
|
Certifications |
ISO 14644-1,ISO 9001,CE |
| Parameter/Feature | Our Product | Market Average | Advantages |
|---|---|---|---|
| H13 Filter Pleat Count | 315 pleats | 260 pleats | Larger filtration area, improving filtration efficiency and dust holding capacity. |
| HEPA Filter | - | - | Increased thickness of filtration media enhances filtration effectiveness and lifespan. |
| Pleat Height | 50 mm | 38 mm | Thicker filtration media improves filtration performance and longevity. |
| Protective Mesh Brand | High-quality 9N brand | Generic brands | Superior support and protection, ensuring structural stability. |
| Frame Thickness | 1.0 mm | 0.7 mm | Stronger frame for enhanced durability and reduced deformation risks. |
| Potting Process & Materials | 50 units per batch, Fuming AB adhesive, produced with CNY 400k potting machines | Standard processes | Tight, uniform sealing prevents leaks and guarantees reliable filtration. |
| Average Airflow Velocity | 0.8 m/s | 0.65 m/s | Higher airflow capacity with lower resistance, boosting system efficiency. |
| Motor | Waterproof | Non-waterproof | Enhanced safety and reliability in diverse environments. |
Key Features
1. Premium Construction: High-quality aluminum-zinc plate ensures durability and corrosion resistance.
2. Advanced Fan System: MRJH® motor with metal impeller delivers large air volume and ultra-low noise.
3. Three-Speed Airflow Control: Adjustable wind speed (0.45–0.95 m/s ±5%) for versatile cleanroom needs.
4. H13 Filtration: Non-partition HEPA filter achieves 99.995% efficiency at 0.3μm particles.
5. Energy Efficiency: Optimized 150W–190W power consumption with 220V/50Hz operation.
6. Stable Performance: Vibration limited to ≤5μm for precision-sensitive environments.
Application Scenarios
Cleanroom air purification in pharmaceutical, electronics, and biotech facilities.
Supplemental filtration for ISO-certified manufacturing zones.
Laboratories requiring H13-grade filtration with customizable airflow settings.
FAQ:
1,Q: What industries are the AC FFU 1175X575X215 Industrial Fan Filter Units designed for?
A: The AC FFU 1175X575X215 is engineered for heavy-duty cleanroom environments such as pharmaceutical production, semiconductor manufacturing, and aerospace facilities. Its industrial-grade construction and HEPA filtration (99.97% efficiency at 0.3μm) meet ISO 14644 Class 5-8 standards, ideal for large-scale contamination-controlled zones.
2,Q: How does the HEPA air purification system ensure cleanroom compliance?
A: This FFU integrates H13/H14 HEPA filters with dual-stage pre-filters, capturing particles as small as 0.1μm (PM0.1). The 1175x575x215mm design provides uniform airflow (0.45 m/s ±10%) across wide cleanroom ceilings, maintaining ISO-mandated air change rates for critical processes.
3,Q: What makes this FFU both energy-saving and low-noise?
A: Featuring a brushless EC motor and aerodynamic fan blades, the unit reduces energy consumption by 40% vs. traditional AC motors, while operating at <52 dB(A). The modular design allows localized air control, minimizing unnecessary airflow and noise in large facilities.
