FFU Laminar Flow Biosafety Cabinet Class 100 Laminar Air Flow Hood
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | MRJH |
| Certification: | ISO 14644,CE,GMP,FDA,UL |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Packaging Details: | Wooden packing |
| Delivery Time: | 7-15 days |
|
Detail Information |
|||
| Condition: | New | Applicable Industries: | Electronics Factory, Food Factory, Laboratory, Dust-free Workshop, Purification Workshop |
|---|---|---|---|
| Weight (KG): | 100 | Showroom Location: | China |
| Video Outgoing-inspection: | Support | Machinery Test Report: | Support |
| Marketing Type: | Hot Product 2020 | Warranty Of Core Components: | 1 |
| Core Components: | Motor, High Efficiency Filter | Warranty: | 2 |
| Key Words: | Laminar Flow Hood | Keyword: | Clean Bench |
| Application: | Dust-free Workshop | Size: | 1200*800*2050 |
| Noise: | 46-58 | Cleanliness: | 100 Class@ 0.3um |
| HEPA Filter: | 99.995%@0.3um Efficiency | Hood Type: | Straight |
| Air Velocity: | 0.75m/s | Material: | Stainless Steel 304 |
| Official Website: | Www.ffu-cleanroom.com | ||
| Highlight: | FFU Laminar Flow Biosafety Cabinet,Class 100 Laminar Flow Biosafety Cabinet,FFU Laminar Air Flow Hood |
||
Product Description
Product Description
|
Shenzhen Meiri Purification Technology Co., Ltd
|
|
|
|
||||
|
CLEAN BENCH SPECIFICATION
|
|
|
|
||||
|
Name
|
Vetical Flow Clean Bench
|
Laminar Flow Clean Bench
|
Laminar Flow Clean Bench
|
||||
|
External Size
(mm) |
1200*600*1800
|
1000*825*1800
|
1200*900*1600
|
||||
|
Internal Size
(mm) |
1124*524*650
|
850*640*620
|
1100*700*720
|
||||
|
Cleanliness
|
Class100 @ 0.3um (99.99-99.99995%)
|
Class100 @ 0.3um (99.99-99.99995%)
|
ISO Grade 5 , FED 209E Class 100
|
||||
|
Noise
|
46-55DB±3DB (Static Testing below 1 M of HEPA )
|
50DB±5DB
|
58DB
|
||||
|
Power
|
220v 50hz/
|
220v 50hz/
|
220v 50hz/ 150~190W±5W
|
||||
|
Application
|
MEDICAL PHARMACY
FOOD INDUSTRY , LIVESTOCK, POWE PLANTS,HEALTHY CARE AND HOSPITAL , RESEARCH INSTITUTION , AEROSPACE TECHNOLOGY AUTO INDUSTRY |
|
|
||||
|
Air Speed (Adjustable)
|
0.45m/s
|
0.45m/s
|
0.45m/s~0.75m/s ±5% (three gears adjustable)
|
||||
|
Ilumination / Accessories
|
Energy Saving Lamp *2 ( Each on the back and front)
|
Clean Lamp*1 / Germicidal Lamp*1 : 18W/8W
|
Clean Lamp*1 / Germicidal Lamp*1 : 18W/8W
|
||||
|
CFU
|
≤0.5cfu/M/0.5H
|
≤0.5cfu/M/0.5H
|
≤0.5cfu/M/0.5H
|
||||
|
Applicable No. of People
|
1 Person
|
1 Person
|
1 person
|
||||
|
Warranty
|
3Years
|
3Years
|
3Years
|
||||
|
Material
|
Full SUS304
|
Outer Coated Cold-rolled Steel Plate / Inner SUS304
|
Outer Coated Cold-rolled Steel Plate / Inner SUS304
|
||||
Self-cleaning Instructions:
A laminar flow hood, also known as a laminar flow cabinet or laminar flow workstation, is a piece of equipment used in laboratories or cleanrooms to provide a controlled and sterile environment for various applications.
The working bench needs to clean for 5 minutes before it can be used.
The first installation needs to be self-cleaning for about 4 hours before it can be used.
The laminar flow hood provided a sterile environment for culturing bacteria without the risk of contamination.
The horizontal laminar flow hood was used for assembly of delicate electronic components, ensuring a particle-free environment.
In the pharmaceutical laboratory, the laminar flow hood was utilized for the aseptic preparation of injectable medications.
The vertical laminar flow hood with UV sterilization allowed for safe manipulation of DNA samples, preventing any external contamination.
Specifications: Dimensions (Mm): W1240*D800*H1450 Work Area Size (Mm): W1200*D600*H600 Housing Material (304) Stainless Steel Working Platform: (304) Stainless Steel Air Speed: 0.45m/S ± 5% Power Supply, Noise: AC220V/50Hz, ≤60db
Recommended Products
Company Profile
Shenzhen Meiri Purification Technology Co., Ltd was established in 2012, is a professional engaged in the research, development, sale and service of air filters, air purification equipment and cleanroom solutions.
We have advanced production and processing and highly automated air purification equipment production line, equipped with dust-free air filter production workshop, can always meet the production requirements of large-scale projects. The company has established a modern quality management system in strict accordance with international standards such as ISO, and its products and production technology have obtained dozens of national patents and international certifications such as CE, UL, ROHS and REACH.
Certifications
Exhibition
Production Line
Design Development
Prepares Materials
Processing
Assemble
Detection
Package
Product Package
FAQ
Q: What’s your sample and production lead time ? A: The lead time for sample takes around 3-7days, mass production lead time is about 2-3 weeks Q: How do you ship the goods ? A: It depends on customer’s demands . If with the full containers , we’d suggest to ship by vessel . If with small order volumes & urgent orders, we’ll suggest to ship by air freight or international couriers . Q: Where is your company located A: Our company & factory are located in Shenzhen , China ( No. 79, Langbei Viallage Industry Road , Tongde Commity , Baolong Stree , Longgang District, Shezhen City , Guangdong Province , China) Q:Can you arrange a visit to your factory? A:Yes,of course. Q:Can you provide customized products as our requirements? A:Yes,of course. Q:Do you test all your products before delivery? A:Yes,of course.We will do 100% test and provide test report before delivery Q:How long is your items delivery time? A:It is normal 10~30 days.Usually it depends on order size,quantity and configuration,etc. Q:What payment term can you accept?What price term can you accept? A:We can accept T/T,L/C,etc.We can accept EXW,FOB,CFR,CIF, DDU,etc. Q:What after-sale service can you provide? A:We can provide 24 hours' technical support online by e-mail,phone,video,etc. Q:How many countries have you exported to?How do you make long-term relationship and cooperation? A:We have exported to over 30 countries in Asia,Middle East,Africa,Europe,North America,South America,etc.We will offer good quality,service and price to ensure our customer satisfaction.We will consider our customer as our friend to help them to solve problems.
