FFU Clean Laminar Flow Hood Sterile Horizontal Laminar Air Flow Cabinet For Laboratory
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | MRJH |
| Certification: | ISO 14644,CE,GMP,FDA,UL |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Packaging Details: | Wooden packing |
| Delivery Time: | 7-15 days |
|
Detail Information |
|||
| Condition: | New | Applicable Industries: | Laboratory |
|---|---|---|---|
| Weight (KG): | 210 | Showroom Location: | China |
| Video Outgoing-inspection: | Support | Machinery Test Report: | Support |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 2 |
| Core Components: | Motor | Warranty: | 2 |
| Product Name: | Horizontal Laminar Flow Hood | Noise: | ≤58db |
| Power Supply: | AC220V / 50Hz | Cleanliness: | Class100-10000 Customized |
| HEPA Filter: | 99.995%@0.3um | Air Velocity: | 0.45 M / S ± 5 % |
| Material: | SUS304/Powder-coated Steel Plate | Clean Level: | ISO5 (Class 100) |
| Work Area Size (Mm): | 1500W (width) X 900D (depth) X 1600H (height). | Rated Powe: | 150-190w ± 5W. |
| Official Website: | Www.ffu-cleanroom.com | ||
| Highlight: | Laboratory Laminar Flow Hood,Horizontal Laminar Flow Hood,FFU Horizontal Laminar Air Flow Cabinet |
||
Product Description
MRJH Using Flow Cabinet Horizontal Sterile Workspace Airflow Hood Ffu Clean Laminar Flow Hood
Product Description
|
Shenzhen Meiri Purification Technology Co., Ltd
|
|
|
|
||||
|
CLEAN BENCH SPECIFICATION
|
|
|
|
||||
|
Name
|
Vetical Flow Clean Bench
|
Laminar Flow Clean Bench
|
Laminar Flow Clean Bench
|
||||
|
External Size
(mm) |
1200*600*1800
|
1000*825*1800
|
1200*900*1600
|
||||
|
Internal Size
(mm) |
1124*524*650
|
850*640*620
|
1100*700*720
|
||||
|
Cleanliness
|
Class100 @ 0.3um (99.99-99.99995%)
|
Class100 @ 0.3um (99.99-99.99995%)
|
ISO Grade 5 , FED 209E Class 100
|
||||
|
Noise
|
46-55DB±3DB (Static Testing below 1 M of HEPA )
|
50DB±5DB
|
58DB
|
||||
|
Power
|
220v 50hz/
|
220v 50hz/
|
220v 50hz/ 150~190W±5W
|
||||
|
Application
|
MEDICAL PHARMACY
FOOD INDUSTRY , LIVESTOCK, POWE PLANTS,HEALTHY CARE AND HOSPITAL , RESEARCH INSTITUTION , AEROSPACE TECHNOLOGY AUTO INDUSTRY |
|
|
||||
|
Air Speed (Adjustable)
|
0.45m/s
|
0.45m/s
|
0.45m/s~0.75m/s ±5% (three gears adjustable)
|
||||
|
Ilumination / Accessories
|
Energy Saving Lamp *2 ( Each on the back and front)
|
Clean Lamp*1 / Germicidal Lamp*1 : 18W/8W
|
Clean Lamp*1 / Germicidal Lamp*1 : 18W/8W
|
||||
|
CFU
|
≤0.5cfu/M/0.5H
|
≤0.5cfu/M/0.5H
|
≤0.5cfu/M/0.5H
|
||||
|
Applicable No. of People
|
1 Person
|
1 Person
|
1 person
|
||||
|
Warranty
|
3Years
|
3Years
|
3Years
|
||||
|
Material
|
Full SUS304
|
Outer Coated Cold-rolled Steel Plate / Inner SUS304
|
Outer Coated Cold-rolled Steel Plate / Inner SUS304
|
||||
Specifications:
1. Full frame is SUS 304. 2. The top is equipped with a stainless steel FFU size 1000*520*250mm. 3. Equipped with aluminum frame high-efficiency filter without partition (995*515*69mm); Efficiency: 100 class 00.13um 99.995% H13. 4. Wind speed: 0.45-0.75m/s ± 58% (three gear adjustable); Fan power supply: 220v 50Hz. 5. Noise: 46-55dB ± 3dB (static test 1m below HEPA) 6. Configured with 4 universal wheels (2 with brakes, 2 without) 7. There are 2 energy-saving lamps inside, each on the back and front. 8. Transparent tempered glass sealed on three sides. 9. The platform evenly punched 5mm; the spacing is 100x100.
