Straight Small Laminar Flow Hood Clean Bench SS 304 Mini Laminar Flow Cabinet
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | MRJH |
| Certification: | ISO 14644,CE,GMP,FDA,UL |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Packaging Details: | Wooden packing |
| Delivery Time: | 7-15 days |
|
Detail Information |
|||
| Condition: | New | Applicable Industries: | Electronics Factory, Food Factory, Laboratory, Dust-free Workshop, Purification Workshop |
|---|---|---|---|
| Weight (KG): | 100 | Showroom Location: | China |
| Video Outgoing-inspection: | Support | Machinery Test Report: | Support |
| Marketing Type: | Hot Product 2020 | Warranty Of Core Components: | 1 |
| Core Components: | Motor, High Efficiency Filter | Warranty: | 2 |
| Key Words: | Laminar Flow Hood | Keyword: | Clean Bench |
| Application: | Dust-free Workshop | Size: | 1200*800*2050 |
| Noise: | 46-58 | Cleanliness: | 100 Class@ 0.3um |
| HEPA Filter: | 99.995%@0.3um Efficiency | Hood Type: | Straight |
| Air Velocity: | 0.75m/s | Material: | Stainless Steel 304 |
| Official Website: | Www.ffu-cleanroom.com | ||
| Highlight: | Straight Small Laminar Flow Hood,SS 304 Small Laminar Flow Hood,SS 304 Mini Laminar Flow Cabinet |
||
Product Description
Product Description
|
Shenzhen Meiri Purification Technology Co., Ltd
|
|
|
|
||||
|
CLEAN BENCH SPECIFICATION
|
|
|
|
||||
|
Name
|
Vetical Flow Clean Bench
|
Laminar Flow Clean Bench
|
Laminar Flow Clean Bench
|
||||
|
External Size
(mm) |
1200*600*1800
|
1000*825*1800
|
1200*900*1600
|
||||
|
Internal Size
(mm) |
1124*524*650
|
850*640*620
|
1100*700*720
|
||||
|
Cleanliness
|
Class100 @ 0.3um (99.99-99.99995%)
|
Class100 @ 0.3um (99.99-99.99995%)
|
ISO Grade 5 , FED 209E Class 100
|
||||
|
Noise
|
46-55DB±3DB (Static Testing below 1 M of HEPA )
|
50DB±5DB
|
58DB
|
||||
|
Power
|
220v 50hz/
|
220v 50hz/
|
220v 50hz/ 150~190W±5W
|
||||
|
Application
|
MEDICAL PHARMACY
FOOD INDUSTRY , LIVESTOCK, POWE PLANTS,HEALTHY CARE AND HOSPITAL , RESEARCH INSTITUTION , AEROSPACE TECHNOLOGY AUTO INDUSTRY |
|
|
||||
|
Air Speed (Adjustable)
|
0.45m/s
|
0.45m/s
|
0.45m/s~0.75m/s ±5% (three gears adjustable)
|
||||
|
Ilumination / Accessories
|
Energy Saving Lamp *2 ( Each on the back and front)
|
Clean Lamp*1 / Germicidal Lamp*1 : 18W/8W
|
Clean Lamp*1 / Germicidal Lamp*1 : 18W/8W
|
||||
|
CFU
|
≤0.5cfu/M/0.5H
|
≤0.5cfu/M/0.5H
|
≤0.5cfu/M/0.5H
|
||||
|
Applicable No. of People
|
1 Person
|
1 Person
|
1 person
|
||||
|
Warranty
|
3Years
|
3Years
|
3Years
|
||||
|
Material
|
Full SUS304
|
Outer Coated Cold-rolled Steel Plate / Inner SUS304
|
Outer Coated Cold-rolled Steel Plate / Inner SUS304
|
||||
Self-cleaning Instructions:
The laminar flow hood offers several advantages due to its ability to provide a controlled and sterile working environment. Here are some key advantages of using a laminar flow hood:
1.The laminar flow hood provided a controlled environment, maintaining the sterility of the samples during the microbiological testing process.
2.By using a laminar flow hood, the laboratory ensured the protection of sensitive electronic components from contaminants during assembly.
3.The laminar flow hood's airflow safeguarded the operator from exposure to hazardous chemicals, ensuring a safe working environment in the chemical laboratory.
1.The laminar flow hood provided a controlled environment, maintaining the sterility of the samples during the microbiological testing process.
2.By using a laminar flow hood, the laboratory ensured the protection of sensitive electronic components from contaminants during assembly.
3.The laminar flow hood's airflow safeguarded the operator from exposure to hazardous chemicals, ensuring a safe working environment in the chemical laboratory.
Specifications:
Dimensions (Mm): W1240*D800*H1450
Work Area Size (Mm): W1200*D600*H600
Housing Material (304) Stainless Steel
Working Platform: (304) Stainless Steel
Air Speed: 0.45m/S ± 5%
Power Supply, Noise: AC220V/50Hz, ≤60db
Recommended Products
Company Profile
Shenzhen Meiri Purification Technology Co., Ltd was established in 2012, is a professional engaged in the research, development, sale and service of air filters, air purification equipment and cleanroom solutions.
We have advanced production and processing and highly automated air purification equipment production line, equipped with dust-free air filter production workshop, can always meet the production requirements of large-scale projects. The company has established a modern quality management system in strict accordance with international standards such as ISO, and its products and production technology have obtained dozens of national patents and international certifications such as CE, UL, ROHS and REACH.
Certifications
Exhibition
Production Line
Design Development
Prepares Materials
Processing
Assemble
Detection
Package
Product Package
