Ultra Thin Housing HEPA Fan Filter Unit with 220V/120V/110V Voltage and Stainless Steel Construction for Cleanrooms
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | MRJH |
| Certification: | ISO,CE,GMP,FDA,UL,ATEX,RoHS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Packaging Details: | Individually packed,<br>Packed in wooden cases,<br>Packing according to customer's requirement |
| Delivery Time: | 7-15 working days |
|
Detail Information |
|||
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other |
|---|---|---|---|
| Weight (KG): | 26 | Showroom Location: | China |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 5 Years |
| Core Components: | Motor | Warranty: | 2 Years |
| Product Name: | Fan Filter Unit Hepa 110v Laminar | Size: | W1175*L575*H215mm Or Custom |
| Weight: | 26kg | Power (Output): | 150-190W±5W |
| Material: | Stainless Steel (201SS / 304SS) / Zinc Alloy Or Custom | Construction: | Panel Filter |
| Noise: | 52-58db±5db | HEPA Air Speed: | 0.45-0.75m/s Or Custom |
| Voltage: | AC/DC 220V/120V/110V, 50Hz Or Custom | Certification: | ISO,CE,UL,RoHS |
| Highlight: | Cleanroom Hepa Fan Filter Unit,Hepa Fan Filter Unit 220V |
||
Product Description
Ultra Thin Housing Hepa Fan Filter Unit 220V / 120V / 110V For Cleanroom
Product Overview
High-performance fan filter unit with HEPA filtration for cleanroom environments, available in 110V, 120V, and 220V configurations.
Technical Specifications
| Product Name | Fan Filter Unit HEPA 110V Laminar |
| Size | W1175 × L575 × H215mm or custom |
| Weight | 26kg |
| Power Output | 150-190W ±5W |
| Material | Stainless Steel (201SS / 304SS) / Zinc Alloy or custom |
| Minimum Order Quantity | 1 piece |
| Customizable | Yes |
| Core Components Warranty | 5 years (Enclosed motor) |
| Full Product Warranty | 2 years |
| Construction | Panel Filter |
| Porosity | 0.3 micron |
| Brand Name | MRJH |
| Noise Level | 52-58db ±5db |
| HEPA Air Speed | 0.45-0.75m/s or custom |
| Voltage | AC/DC 220V/120V/110V, 50Hz or custom |
Applications
- Clean Rooms
- Dust-free Production Workshops
- Pharmaceutical Companies
- Modernization Plants
- Automated Manufacturing Factories
- Laboratories
- Mycology Facilities
- Hotels and Commercial Spaces
Competitive Advantages
| Parameter/Feature | Our Product | Market Average | Advantages |
|---|---|---|---|
| Filter Pleat Count | 315 pleats | 260 pleats | Larger filtration area, improving filtration efficiency and dust holding capacity |
| Pleat Height | 50 mm | 38 mm | Thicker filtration media improves filtration performance and longevity |
| Protective Mesh Brand | High-quality 9N brand | Generic brands | Superior support and protection, ensuring structural stability |
| Frame Thickness | 1.0 mm | 0.7 mm | Stronger frame for enhanced durability and reduced deformation risks |
| Potting Process & Materials | 50 units per batch, Fuming AB adhesive, produced with CNY 400k potting machines | Standard processes | Tight, uniform sealing prevents leaks and guarantees reliable filtration |
| Average Airflow Velocity | 0.8 m/s | 0.65 m/s | Higher airflow capacity with lower resistance, boosting system efficiency |
| Motor | Waterproof | Non-waterproof | Enhanced safety and reliability in diverse environments |
Product Gallery
Applications & Compatibility
Fan filter unit is applicable for Class 10-100,000 dust-free workshops, which is convenient for the overall use of group control system.
FFU is also applicable for manufacturer-class optical, biological industries of semiconductors, electronics, flat panel displays and disk drives, and other areas with strictly control requirements for air pollution.
Product Features
Improved Air Intake Design
Large area air inlet for efficient and rapid purification, equipped with protective cover for effective air intake protection.
Glass Fiber Cartridge Filter
High efficiency filtration with superior performance.
Insulated Handle
Perfect detail design for easy and safe operation.
Multiple Impeller Options
Aluminum Impeller
PP Impeller
Iron Impeller
Available Stock & Fast Delivery
Company Profile
Welcome to Visit Our Factory
Shenzhen Meiri Purification Technology Co., Ltd. Our products and production technology have obtained dozens of national patents and international certifications such as CE, UL, ROHS, and REACH. We consistently meet the production requirements of large-scale projects.
Multiple AMADA Turret CNC Punch Presses
FFU Production Line
AMADA CNC Bending Machine
Key Features
Low Noise
Anti-Static
Waterproof
Low Temperature
Leakage Resistance
High Quality Sheet Metal - Beautiful and Durable Surface
High Quality Sheet Metal - Beautiful and Durable Surface
Customization & After-Sales Service
All products can be customized in size and style according to any customer special requirements. Professional after-sales service with one-to-one online processing and timely feedback for one-stop service support.
Certificates - Verifiable and Welcome to Factory Visit
Frequently Asked Questions
What's your sample and production lead time?
The lead time for sample takes around 3-7 days, mass production lead time is about 2-3 weeks.
How do you ship the goods?
It depends on customer's demands. For full containers, we suggest shipping by vessel. For small order volumes & urgent orders, we suggest shipping by air freight or international couriers.
Where is your company located?
Our company & factory are located in Shenzhen, China (No. 79, Langbei Village Industry Road, Tongde Community, Baolong Street, Longgang District, Shenzhen City, Guangdong Province, China).
Can you arrange a visit to your factory?
Yes, of course.
Can you provide customized products as per our requirements?
Yes, of course.
Do you test all your products before delivery?
Yes, of course. We perform 100% testing and provide test reports before delivery.
How long is your items delivery time?
Typically 10-30 days, depending on order size, quantity, and configuration.
What payment terms can you accept? What price terms can you accept?
We accept T/T, L/C, etc. We accept EXW, FOB, CFR, CIF, DDU, etc.
What after-sale service can you provide?
We provide 24-hour technical support online via email, phone, video, etc.
How many countries have you exported to? How do you maintain long-term relationships and cooperation?
We have exported to over 30 countries in Asia, Middle East, Africa, Europe, North America, and South America. We offer good quality, service, and pricing to ensure customer satisfaction. We treat our customers as friends and help them solve problems.
