Product Details:

Place of Origin: Guangdong, China
Brand Name: MRJH
Certification: ISO 14644,EU GMP,FDA
Model Number: MRJH - FLCDC600Q201

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Contact Us
Packaging Details: Wooden frame
Delivery Time: 7-15 days
Get Best Price Contact Now

Detail Information
External Dimensions: W770 × D690 × H1500 (mm) Air Shower Area: W600 × D600 × H600 (mm)
Custom Made: Support Official Website: Www.ffu-cleanroom.com
Certification: ISO,CE,UL,RoHS
Highlight:

Pharma Cleanrooms Air Shower

,

Electronics Cleanrooms Air Shower

,

HEPA H13 Air Shower

Product Description

ISO-Certified Air Shower Pass Box | 201 Stainless Steel & HEPA H13 | Pharma/Electronics Cleanrooms


A high-efficiency filtration system, including HEPA H14 filters (≥99.995% efficiency at 0.3μm), ensures laminar airflow with velocities of 13–25 m/s, effectively removing particulate contaminants and preventing cross-contamination. The adjustable air nozzles deliver targeted airflow for thorough decontamination of materials, while the system’s electronic interlocking mechanism prevents simultaneous door openings, maintaining cleanroom pressure differentials and aseptic conditions.


Parameter Name

 parameter
Material 201 stainless steel
Window Design Double-layer tempered glass with silk-screened black edges
Air Shower System 4 adjustable stainless steel air nozzles
Control System Panel control with dual-door electronic interlock
Fan System 220V/50Hz air shower fan, nozzle outlet speed: 13–25 m/s
Filtration 2 pre-filters + 1 high-efficiency filter (99.99% efficiency)
Lighting Clean lighting LED lamp
Door System Flat door design with pressure handles for airtight sealing
Internal Design Rounded internal corners for easy cleaning and GMP compliance
Manufacturing Process Laser cutting, CNC bending, and laser welding for precision and aesthetics
External Dimensions W770 × D690 × H1500 (mm)
Internal Dimensions W600 × D600 × H600 (mm)
Certifications ISO ,GMP,CE

ISO-Certified Air Shower Pass Box | 201 Stainless Steel & HEPA H13 | Pharma/Electronics Cleanrooms 0


Key Features

1. 201 Stainless Steel Construction: Durable and corrosion-resistant for cleanroom compatibility.

2. Aesthetic & Functional Design: Double-layer tempered glass with black edges for visibility and style.

3. High-Efficiency Air Shower: 4 adjustable nozzles with 13–25 m/s wind speed for rapid decontamination.

4. Smart Control: Panel control with dual-door electronic interlock to prevent cross-contamination.

5. Advanced Filtration: 2 pre-filters + 1 HEPA filter ensure 99.99% efficiency.

6. Clean Lighting: Integrated LED lamp for illumination during transfers.

7. GMP Compliance: Rounded internal corners and flat door design for easy cleaning and high-end appearance.

Application Scenarios

Material transfer in pharmaceutical cleanrooms.

Sterile sample handling in biomedical laboratories.

Contamination-sensitive component transfer in electronics manufacturing.


ISO-Certified Air Shower Pass Box | 201 Stainless Steel & HEPA H13 | Pharma/Electronics Cleanrooms 1

ISO-Certified Air Shower Pass Box | 201 Stainless Steel & HEPA H13 | Pharma/Electronics Cleanrooms 2


ISO-Certified Air Shower Pass Box | 201 Stainless Steel & HEPA H13 | Pharma/Electronics Cleanrooms 3

ISO-Certified Air Shower Pass Box | 201 Stainless Steel & HEPA H13 | Pharma/Electronics Cleanrooms 4

ISO-Certified Air Shower Pass Box | 201 Stainless Steel & HEPA H13 | Pharma/Electronics Cleanrooms 5

ISO-Certified Air Shower Pass Box | 201 Stainless Steel & HEPA H13 | Pharma/Electronics Cleanrooms 6


Q1: How does this ISO-certified air shower maintain compliance with strict cleanliness standards in pharmaceutical and electronics cleanrooms?
A1: This air shower is designed to meet ISO 14644-1 Class 5 (ISO 5) cleanroom requirements, ensuring particle-free entry/exit for personnel or equipment. The HEPA H13 filters achieve ≥99.99% efficiency at capturing particles ≥0.3μm, while the laminar airflow system (20–30 m/s velocity) creates a unidirectional air curtain to prevent contamination. The 201 stainless steel interior offers a smooth, non-porous surface that resists particle buildup and is easy to sanitize, critical for GMP and FDA-compliant environments. Automatic interlocking doors and optional UV-C sterilization further eliminate cross-contamination risks, making it ideal for pharmaceutical manufacturing, electronics assembly, or other sterile processes where ISO compliance is essential.

Q2: Can the 201 stainless steel construction withstand frequent use and chemical exposure in pharmaceutical or electronics settings?
A2: Yes. 201 stainless steel provides corrosion resistance and durability, making it suitable for environments with mild chemical exposure or frequent sanitization. Its smooth finish minimizes dust and debris accumulation, simplifying maintenance and reducing contamination risks. The air shower is engineered for heavy use, with robust components like reinforced hinges and high-quality seals that maintain airtight integrity over time. For highly corrosive applications, optional upgrades to 316L stainless steel are available. Regular cleaning (weekly wipe-downs) and filter maintenance (pre-filters every 1–6 months, HEPA filters every 6–12 months) ensure long-term performance in demanding cleanroom environments.

Q3: How does the HEPA H13 filtration system in this air shower handle high-traffic operations while maintaining efficiency?
A3: The HEPA H13 filters are designed to sustain high airflow rates (up to 2000 CFM) while maintaining 99.99% efficiency, even during continuous use. The air shower’s dual blower system and strategically placed nozzles ensure uniform particle removal across all surfaces, even in high-traffic scenarios. Pressure sensors monitor filter performance, alerting operators when replacements are needed to prevent airflow obstruction. The modular design allows easy access to filter compartments, streamlining maintenance and reducing downtime. This combination of robust filtration, intelligent design, and user-friendly maintenance ensures consistent efficiency in pharmaceutical or electronics cleanrooms where continuous particle control is critical to product quality.
