ISO 10 UV Light Laminar Flow Pass Box for Clean Room Transfer Window with Seamless Connection
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | MRJH |
| Certification: | ISO 14644,EU GMP,FDA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Packaging Details: | Individually packed,<br>Packed in wooden cases,<br>Packing according to customer's requirement |
| Delivery Time: | 7-15 working days |
| Supply Ability: | 300 Set/Sets per Week |
|
Detail Information |
|||
| Features: | Internal Arc Treatment, Seamless Connection | Condition: | New |
|---|---|---|---|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advert | Weight (KG): | 55 |
| Showroom Location: | None | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | Ordinary Product |
| Warranty Of Core Components: | 5 Years | Core Components: | Motor |
| Warranty: | 2 Years | Product: | Pass Box |
| Material: | Aluminum / Steel / SS. / Custom | Use: | Reduce The Contamination Of Clean Rooms From Small Items |
| Add-on Features: | Allowed, Please Contact Us | Locks: | Mechanical Locks / Electronic Locks |
| Buzzer,Walkie-talkie: | Supported Options Custom | Air Shower,Laminar Flow: | Supported Options Custom |
| DOP,Barometer: | Supported Options Custom | Landing And Lifting: | Supported Options Custom |
| Port: | ShenZhen Port, Acording To Customer Requirements | Certification: | ISO,CE,UL,RoHS |
| Highlight: | ISO 10 UV light pass box,laminar flow clean room transfer window,seamless connection clean room pass box |
||
Product Description
ISO 10 UV Light Laminar Flow Pass Box for Laboratory
Customized Laboratory Pass Box Solutions
We offer customized static pass boxes, static mechanical interlocking pass boxes, and accept OEM/ODM projects to meet your specific laboratory requirements.
Product Specifications
- Product: Pass Box
- Material: Aluminum / Steel / Stainless Steel / Custom
- Use: Reduce contamination of clean rooms from small items transfer
- Features: Internal arc treatment, seamless connection
- Locks: Mechanical locks
- Add-on Features: Available upon request
Applications
Medical pharmacy, food industry, livestock, power plants, healthcare and hospitals, research institutions, aerospace technology, and auto industry.
Technical drawings available upon request
Consult and get your own engineering consultant!
Product Introduction
As auxiliary equipment for clean rooms, transfer windows are primarily used for transferring small items between clean areas, unclean areas, and clean areas. This reduces the opening times of clean room doors and minimizes contamination of clean areas to the greatest extent.
Air shower rooms are equipped with high-velocity air jets strategically positioned to blow clean air onto individuals or objects, effectively removing particles and contaminants.
Air shower rooms feature interlocking entry and exit doors to ensure individuals must pass through the air shower before entering or leaving the clean area.
Application Showcase
Product Specifications Table
| Model | External Dimensions | Internal Dimensions | Material | Weight |
|---|---|---|---|---|
| Mechanical Lock Pass Box | ||||
| 400CS | W 560mm D 480mm H 520mm | W 400mm D 400mm H 400mm | External: Coated Cold Steel Internal: 304 |
30 kg |
| 400SS | W 560mm D 480mm H 520mm | W 400mm D 400mm H 400mm | All 304 | 33 kg |
| 600CS | W 760mm D 680mm H 720mm | W 600mm D 600mm H 600mm | External: Coated Cold Steel Internal: 304 |
45 kg |
| 600SS | W 760mm D 680mm H 720mm | W 600mm D 600mm H 600mm | All 304 | 50 kg |
| 800CS | W 960mm D 880mm H 920mm | W 800mm D 800mm H 800mm | External: Coated Cold Steel Internal: 304 |
60 kg |
| 800SS | W 960mm D 880mm H 920mm | W 800mm D 800mm H 800mm | All 304 | 66 kg |
| GMP Electronic Lock Pass Box | ||||
| 400GCS | W 600mm D 490mm H 560mm | W 400mm D 400mm H 400mm | External: Coated Cold Steel Internal: 304 |
33 kg |
| 400GSS | W 600mm D 490mm H 560mm | W 400mm D 400mm H 400mm | All 304 | 40 kg |
| 600GCS | W 800mm D 690mm H 760mm | W 600mm D 600mm H 600mm | External: Coated Cold Steel Internal: 304 |
43 kg |
| 600GSS | W 800mm D 690mm H 760mm | W 600mm D 600mm H 600mm | All 304 | 55 kg |
| 800GCS | W 1100mm D 890mm H 960mm | W 800mm D 800mm H 800mm | External: Coated Cold Steel Internal: 304 |
59 kg |
| 800GSS | W 1100mm D 890mm H 960mm | W 800mm D 800mm H 800mm | All 304 | 69 kg |
| Air Shower Pass Box | ||||
| 600FCS | W 950mm D 680mm H 1550mm | W 600mm D 600mm H 600mm | External: Coated Cold Steel Internal: 304 |
70 kg |
| 600FSS | W 950mm D 680mm H 1550mm | W 600mm D 600mm H 600mm | All 304 | 89 kg |
| 800FCS | W 1550mm D 880mm H 1750mm | W 800mm D 800mm H 800mm | External: Coated Cold Steel Internal: 304 |
100 kg |
| 800FSS | W 1550mm D 880mm H 1750mm | W 800mm D 800mm H 800mm | All 304 | 118 kg |
| 1000FCS | W 1350mm D 1080mm H 1950mm | W 1000mm D 1000mm H 1000mm | External: Coated Cold Steel Internal: 304 |
130 kg |
| 1000FSS | W 1350mm D 1080mm H 1950mm | W 1000mm D 1000mm H 1000mm | All 304 | 148 kg |
| Laminar Flow Pass Box | ||||
| 400LCS | W 600mm D 490mm H 1000mm | W 400mm D 400mm H 400mm | External: Coated Cold Steel Internal: 304 |
59 kg |
| 400LSS | W 600mm D 490mm H 1000mm | W 400mm D 400mm H 400mm | All 304 | 78 kg |
| 600LCS | W 800mm D 690mm H 1200mm | W 600mm D 600mm H 600mm | External: Coated Cold Steel Internal: 304 |
83 kg |
| 600LSS | W 800mm D 690mm H 1200mm | W 600mm D 600mm H 600mm | All 304 | 100 kg |
| 800LCS | W 1100mm D 890mm H 1400mm | W 800mm D 800mm H 800mm | External: Coated Cold Steel Internal: 304 |
112 kg |
| 800LSS | W 1100mm D 890mm H 1400mm | W 800mm D 800mm H 800mm | All 304 | 145 kg |
Free Customization
Factory Direct Sales
Quality Assurance
High Quality Material
Strong and Durable
No Worries After Sale
The air supply in air shower rooms is filtered through high-efficiency particulate air (HEPA) filters to remove particles and maintain a clean airflow.
About Shenzhen Meiri Purification Technology Co., Ltd
Founded in 2012, we specialize in the research, development, sales, and service of air filters, air purification equipment, and clean room solutions. Our clean production hall is equipped with advanced manufacturing capabilities including:
- 2 AMABA automatic CNC presses
- 5 automatic CNC bending machines
- 5 sheering machines
- Multiple bending machines
- 2 interactive laser engraving machines
With advanced air purification equipment production and highly automated machine lines, our products and production technology have obtained dozens of national patents and international certifications including CE, UL, ROHS, and REACH. We consistently meet the production requirements of large-scale projects.
Multiple AMADA Turret CNC Punch Presses
FFU Production Line
AMADA CNC Bending Machine
High quality sheet metal - Beautiful and durable surface
1300×1300 High Efficiency Filter Production Line
2000 Watt Laser
Integrated Laser Cutting and Tube Cutting Machine
French KIMO Noise Meter
FFU Motor Testing Equipment
KIMO Anemometer
GMW Multi-function Tester
METOTE Dust Particle Detector
TSI Air Volume Cover
Technology Guardian of Health
Certificate can be verified
Frequently Asked Questions
Q: What's your sample and production lead time?
A: The lead time for sample takes around 3-7 days, mass production lead time is about 2-3 weeks.
Q: How do you ship the goods?
A: It depends on customer's demands. If with the full containers, we'd suggest to ship by vessel. If with small order volumes & urgent orders, we'll suggest to ship by air freight or international couriers.
Q: Where is your company located?
A: Our company & factory are located in Shenzhen, China (No. 79, Langbei Village Industry Road, Tongde Community, Baolong Street, Longgang District, Shenzhen City, Guangdong Province, China).
Q: What payment term can you accept? What price term can you accept?
A: We can accept T/T, L/C, etc. We can accept EXW, FOB, CFR, CIF, DDU, etc.
Q: What after-sale service can you provide?
A: We can provide 24 hours' technical support online by e-mail, phone, video, etc.
Q: How many countries have you exported to? How do you make long-term relationship and cooperation?
A: We have exported to over 30 countries in Asia, Middle East, Africa, Europe, North America, South America, etc. We will offer good quality, service and price to ensure our customer satisfaction. We will consider our customer as our friend to help them to solve problems.
