Customizable Stainless Steel Clean Room Pass Box with Mechanical Interlock for Laboratory Use
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | MRJH |
| Certification: | ISO 14644,EU GMP,FDA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Packaging Details: | Individually packed,<br>Packed in wooden cases,<br>Packing according to customer's requirement |
| Delivery Time: | 7-15 working days |
| Supply Ability: | 300 Set/Sets per Week |
|
Detail Information |
|||
| Features: | Internal Arc Treatment, Seamless Connection | Condition: | New |
|---|---|---|---|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advert | Weight (KG): | 55 |
| Showroom Location: | None | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | Ordinary Product |
| Warranty Of Core Components: | 5 Years | Core Components: | Motor |
| Warranty: | 2 Years | Product: | Pass Box |
| Material: | Aluminum / Steel / SS. / Custom | Use: | Reduce The Contamination Of Clean Rooms From Small Items |
| Add-on Features: | Allowed, Please Contact Us | Locks: | Mechanical Locks / Electronic Locks |
| Buzzer,Walkie-talkie: | Supported Options Custom | Air Shower,Laminar Flow: | Supported Options Custom |
| DOP,Barometer: | Supported Options Custom | Landing And Lifting: | Supported Options Custom |
| Port: | ShenZhen Port, Acording To Customer Requirements | Certification: | ISO,CE,UL,RoHS |
| Highlight: | Laboratory Clean Room Pass Box,Custom Clean Room Pass Box,Biotechnology Dynamic Pass Through Box |
||
Product Description
Customized Lab Pass Box Static Pass Box Static Mechanical Interlocking Pass Box OEM/ODM Acceptable
| Product | Pass Box |
|---|---|
| Material | Aluminum / Steel / Stainless Steel / Custom |
| Use | Reduce the contamination of clean rooms from small items |
| Application | Medical, Pharmacy, Food Industry, Livestock, Power Plants, Healthcare and Hospital, Research Institution, Aerospace Technology, Auto Industry |
| Features | Internal arc treatment, seamless connection |
| Add-on Features | Allowed, Please contact us |
| Locks | Mechanical locks |
| Buzzer, Walkie-talkie | Supported Options Custom |
| Air shower, Laminar flow | Supported Options Custom |
| DOP, Barometer | Supported Options Custom |
| Landing and lifting | Supported Options Custom |
More drawings available...
As an auxiliary equipment of clean room, transfer window is mainly used for the transfer of small items between clean area, unclean area and clean area, so as to reduce the opening times of clean room door and reduce the pollution of clean area to the greatest extent.
- Stainless steel door hinge, all stainless steel handle
- Tempered glass observation windows, EVA high-performance sealing
- 8cm round steel mechanical interlock or imported electronic interlock
More types are updating...
| Model | Outer Size | Inner Size | Material | Weight |
|---|---|---|---|---|
| 400CS | W 560 mm D 480 mm H 520 mm | W 400 mm D 400 mm H 400 mm | External: Coated Cold Steel Internal: 304 | 30 kg |
| 400SS | W 560 mm D 480 mm H 520 mm | W 400 mm D 400 mm H 400 mm | All 304 | 33 kg |
| 600CS | W 760 mm D 680 mm H 720 mm | W 600 mm D 600 mm H 600 mm | External: Coated Cold Steel Internal: 304 | 45 kg |
| 600SS | W 760 mm D 680 mm H 720 mm | W 600 mm D 600 mm H 600 mm | All 304 | 50 kg |
| 800CS | W 960 mm D 880 mm H 920 mm | W 800 mm D 800 mm H 800 mm | External: Coated Cold Steel Internal: 304 | 60 kg |
| 800SS | W 960 mm D 880 mm H 920 mm | W 800 mm D 800 mm H 800 mm | All 304 | 66 kg |
| Model | Outer Size | Inner Size | Material | Weight |
|---|---|---|---|---|
| 400GCS | W 600 mm D 490 mm H 560 mm | W 400 mm D 400 mm H 400 mm | External: Coated Cold Steel Internal: 304 | 33 kg |
| 400GSS | W 600 mm D 490 mm H 560 mm | W 400 mm D 400 mm H 400 mm | All 304 | 40 kg |
| 600GCS | W 800 mm D 690 mm H 760 mm | W 600 mm D 600 mm H 600 mm | External: Coated Cold Steel Internal: 304 | 43 kg |
| 600GSS | W 800 mm D 690 mm H 760 mm | W 600 mm D 600 mm H 600 mm | All 304 | 55 kg |
| 800GCS | W 1100 mm D 890 mm H 960 mm | W 800 mm D 800 mm H 800 mm | External: Coated Cold Steel Internal: 304 | 59 kg |
| 800GSS | W 1100 mm D 890 mm H 960 mm | W 800 mm D 800 mm H 800 mm | All 304 | 69 kg |
| Model | Outer Size | Inner Size | Material | Weight |
|---|---|---|---|---|
| 400LCS | W 600 mm D 490 mm H 1000 mm | W 400 mm D 400 mm H 400 mm | External: Coated Cold Steel Internal: 304 | 59 kg |
| 400LSS | W 600 mm D 490 mm H 1000 mm | W 400 mm D 400 mm H 400 mm | All 304 | 78 kg |
| 600LCS | W 800 mm D 690 mm H 1200 mm | W 600 mm D 600 mm H 600 mm | External: Coated Cold Steel Internal: 304 | 83 kg |
| 600LSS | W 800 mm D 690 mm H 1200 mm | W 600 mm D 600 mm H 600 mm | All 304 | 100 kg |
| 800LCS | W 1100 mm D 890 mm H 1400 mm | W 800 mm D 800 mm H 800 mm | External: Coated Cold Steel Internal: 304 | 112 kg |
| 800LSS | W 1100 mm D 890 mm H 1400 mm | W 800 mm D 800 mm H 800 mm | All 304 | 145 kg |
Free Customization
Factory Direct Sales
Quality Assurance
High Quality Material
Strong and Durable
No Worries After Sale
Shenzhen Meiri Purification Technology Co., Ltd
With advanced air purification equipment production and processing and highly automated machine lines, our products and production technology have obtained dozens of national patents and international certifications such as CE, UL, ROHS, and REACH. So far, we have always been able to meet the production requirements of large-scale projects.
Multiple AMADA Turret CNC Punch Presses
FFU Production Line
AMADA CNC Bending Machine
1300×1300 High Efficiency Filter Production Line
2000 Watt Laser
Integrated Laser Cutting and Tube Cutting Machine
French KIMO Noise Meter
FFU Motor Testing Equipment
KIMO Anemometer
It creates a healthier working environment by reducing airborne pollutants and improving the overall air quality within office spaces.
Certificate can be verified. Welcome to the factory field visit.
A: The lead time for sample takes around 3-7 days, mass production lead time is about 2-3 weeks.
A: It depends on customer's demands. If with the full containers, we'd suggest to ship by vessel. If with small order volumes & urgent orders, we'll suggest to ship by air freight or international couriers.
A: Our company & factory are located in Shenzhen, China (No. 79, Langbei Village Industry Road, Tongde Community, Baolong Street, Longgang District, Shenzhen City, Guangdong Province, China)
A: Yes, of course.
A: Yes, of course.
A: Yes, of course. We will do 100% test and provide test report before delivery.
A: It is normal 10~30 days. Usually it depends on order size, quantity and configuration, etc.
A: We can accept T/T, L/C, etc. We can accept EXW, FOB, CFR, CIF, DDU, etc.
A: We can provide 24 hours' technical support online by e-mail, phone, video, etc.
A: We have exported to over 30 countries in Asia, Middle East, Africa, Europe, North America, South America, etc. We will offer good quality, service and price to ensure our customer satisfaction. We will consider our customer as our friend to help them to solve problems.
