Seamless Connection Mechanical Interlock 304 Stainless Steel Clean Room Pass Box for Biotechnology Pass Through Cabinet
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | MRJH |
| Certification: | ISO 14644,EU GMP,FDA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Packaging Details: | Individually packed,<br>Packed in wooden cases,<br>Packing according to customer's requirement |
| Delivery Time: | 7-15 working days |
| Supply Ability: | 500 Set/Sets per Day |
|
Detail Information |
|||
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advert |
|---|---|---|---|
| Weight (KG): | 26 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2022 | Warranty Of Core Components: | 2 Years |
| Core Components: | Box Of Metal | Warranty: | 2 Years |
| Product Name: | Pass Box | Material: | Outer Cold Rolled Steel; Inter 304 Stainless Steel |
| After-sales Service Provided: | 5 Years | Lock: | Mechanical Interlock |
| Door: | Flat Door | External Size: | Custom |
| Internal Size: | Custom | Port: | ShenZhen Port, Acording To Customer Requirements |
| Certification: | ISO,CE,UL,RoHS | ||
| Highlight: | Seamless Connection Clean Room Pass Box,Biotechnology Clean Room Pass Box,Biotechnology Pass Through Cabinet |
||
Product Description
Seamless Connection Clean Room Pass Box For Biotechnology Pass Through Cabinet
Our Advantages
- Professional manufacturer with 12 years of experience
- 20,000㎡ factory facility
- Leading company in the clean room industry
- More than 300 employees including R&D and production teams
- Accept R&D, sampling, production and mass production of non-standard products
- Fast delivery of standard products
- Two years warranty
- Main products include: FFU, air shower room, cargo shower room, clean washbasin, laminar flow hood, clean room, pass box, HEPA filter, providing one-stop solutions
- 24 hours online services
Customized UV Pass Box, Price of Pass Box & Pass Box for Clean Room OEM/ODM Acceptable
Specifications
| Product | Pass Box |
|---|---|
| Material | Aluminum / Steel / Stainless Steel / Custom |
| Use | Reduce contamination of clean rooms from small items |
| Application | Medical, Pharmacy, Food Industry, Livestock, Power Plants, Healthcare and Hospital, Research Institution, Aerospace Technology, Auto Industry |
| Features | Internal arc treatment, seamless connection |
| Add-on Features | Allowed, Please contact us |
| Locks | Mechanical locks |
| Buzzer, Walkie-talkie | Supported Options Custom |
| Air Shower, Laminar Flow | Supported Options Custom |
| DOP, Barometer | Supported Options Custom |
| Landing and Lifting | Supported Options Custom |
More drawings available...
Consult and get your own engineering consultant!
Product Introduction
Mechanical Interlocking Pass Box
The mechanical interlocking pass box, also known as a mechanical interlock transfer box, is specialized equipment commonly used in controlled environments such as cleanrooms, laboratories, or manufacturing facilities.
Key Features
- Material Transfer: Facilitates transfer of materials or products between two controlled environments while maintaining integrity and cleanliness
- Interlocking Mechanism: Ensures only one door can be opened at a time, preventing cross-contamination
- Contamination Control: Designed to minimize contamination risk with air filtration systems including HEPA filters
Product Details
GMP Electronic Interlocking Transfer Window
- Stainless steel door hinge, all stainless steel handle
- Tempered glass observation windows, EVA high-performance sealing
- 8cm round steel mechanical interlock or imported electronic interlock
Application Show
More types are updating...
Omit the decimal point number, manual measurement will have a small error
Product Specifications Table
Mechanical Lock Pass Box
| Model | Out Size | In Size | Material | Weight |
|---|---|---|---|---|
| 400CS | W 560mm D 480mm H 520mm | W 400mm D 400mm H 400mm | External: Coated Cold Steel Internal: 304 | 30 kg |
| 400SS | W 560mm D 480mm H 520mm | W 400mm D 400mm H 400mm | All 304 | 33 kg |
| 600CS | W 760mm D 680mm H 720mm | W 600mm D 600mm H 600mm | External: Coated Cold Steel Internal: 304 | 45 kg |
| 600SS | W 760mm D 680mm H 720mm | W 600mm D 600mm H 600mm | All 304 | 50 kg |
| 800CS | W 960mm D 880mm H 920mm | W 800mm D 800mm H 800mm | External: Coated Cold Steel Internal: 304 | 60 kg |
| 800SS | W 960mm D 880mm H 920mm | W 800mm D 800mm H 800mm | All 304 | 66 kg |
GMP Electronic Lock Pass Box
| Model | Out Size | In Size | Material | Weight |
|---|---|---|---|---|
| 400GCS | W 600mm D 490mm H 560mm | W 400mm D 400mm H 400mm | External: Coated Cold Steel Internal: 304 | 33 kg |
| 400GSS | W 600mm D 490mm H 560mm | W 400mm D 400mm H 400mm | All 304 | 40 kg |
| 600GCS | W 800mm D 690mm H 760mm | W 600mm D 600mm H 600mm | External: Coated Cold Steel Internal: 304 | 43 kg |
| 600GSS | W 800mm D 690mm H 760mm | W 600mm D 600mm H 600mm | All 304 | 55 kg |
| 800GCS | W 1100mm D 890mm H 960mm | W 800mm D 800mm H 800mm | External: Coated Cold Steel Internal: 304 | 59 kg |
| 800GSS | W 1100mm D 890mm H 960mm | W 800mm D 800mm H 800mm | All 304 | 69 kg |
Air Shower Pass Box
| Model | Out Size | In Size | Material | Weight |
|---|---|---|---|---|
| 600FCS | W 950mm D 680mm H 1550mm | W 600mm D 600mm H 600mm | External: Coated Cold Steel Internal: 304 | 70 kg |
| 600FSS | W 950mm D 680mm H 1550mm | W 600mm D 600mm H 600mm | All 304 | 89 kg |
| 800FCS | W 1550mm D 880mm H 1750mm | W 800mm D 800mm H 800mm | External: Coated Cold Steel Internal: 304 | 100 kg |
| 800FSS | W 1550mm D 880mm H 1750mm | W 800mm D 800mm H 800mm | All 304 | 118 kg |
| 1000FCS | W 1350mm D 1080mm H 1950mm | W 1000mm D 1000mm H 1000mm | External: Coated Cold Steel Internal: 304 | 130 kg |
| 1000FSS | W 1350mm D 1080mm H 1950mm | W 1000mm D 1000mm H 1000mm | All 304 | 148 kg |
Laminar Flow Pass Box
| Model | Out Size | In Size | Material | Weight |
|---|---|---|---|---|
| 400LCS | W 600mm D 490mm H 1000mm | W 400mm D 400mm H 400mm | External: Coated Cold Steel Internal: 304 | 59 kg |
| 400LSS | W 600mm D 490mm H 1000mm | W 400mm D 400mm H 400mm | All 304 | 78 kg |
| 600LCS | W 800mm D 690mm H 1200mm | W 600mm D 600mm H 600mm | External: Coated Cold Steel Internal: 304 | 83 kg |
| 600LSS | W 800mm D 690mm H 1200mm | W 600mm D 600mm H 600mm | All 304 | 100 kg |
| 800LCS | W 1100mm D 890mm H 1400mm | W 800mm D 800mm H 800mm | External: Coated Cold Steel Internal: 304 | 112 kg |
| 800LSS | W 1100mm D 890mm H 1400mm | W 800mm D 800mm H 800mm | All 304 | 145 kg |
Too complicated for choices? Contact our customer service, direct access to the product you want!
Free Customization
Factory Direct Sales
Quality Assurance
High Quality Material
Strong and Durable
No Worries After Sale
Frequently Asked Questions
Q: What's your sample and production lead time?
A: The lead time for sample takes around 3-7 days, mass production lead time is about 2-3 weeks.
Q: How do you ship the goods?
A: It depends on customer's demands. If with the full containers, we'd suggest to ship by vessel. If with small order volumes & urgent orders, we'll suggest to ship by air freight or international couriers.
Q: Where is your company located?
A: Our company & factory are located in Shenzhen, China (No. 79, Langbei Village Industry Road, Tongde Community, Baolong Street, Longgang District, Shenzhen City, Guangdong Province, China).
Q: Can you arrange a visit to your factory?
A: Yes, of course.
Q: Can you provide customized products as our requirements?
A: Yes, of course.
Q: Do you test all your products before delivery?
A: Yes, of course. We will do 100% test and provide test report before delivery.
Q: How long is your items delivery time?
A: It is normal 10~30 days. Usually it depends on order size, quantity and configuration, etc.
Q: What payment term can you accept? What price term can you accept?
A: We can accept T/T, L/C, etc. We can accept EXW, FOB, CFR, CIF, DDU, etc.
Q: What after-sale service can you provide?
A: We can provide 24 hours' technical support online by e-mail, phone, video, etc.
Q: How many countries have you exported to? How do you make long-term relationship and cooperation?
A: We have exported to over 30 countries in Asia, Middle East, Africa, Europe, North America, South America, etc. We will offer good quality, service and price to ensure our customer satisfaction. We will consider our customer as our friend to help them to solve problems.
