GMP Grade Stainless Steel Pass Box with Electronic Interlock for Cleanroom Transfer
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | MRJH |
| Certification: | ISO 14644,EU GMP,FDA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Packaging Details: | Individually packed,<br>Packed in wooden cases,<br>Packing according to customer's requirement |
| Delivery Time: | 7-15 working days |
| Supply Ability: | 2000 Box/Boxes per Day |
|
Detail Information |
|||
| Features: | Internal Arc Treatment, Seamless Connection | Condition: | New |
|---|---|---|---|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advert | Weight (KG): | 33 |
| Showroom Location: | China | Video Outgoing-inspection: | Support |
| Machinery Test Report: | Support | Marketing Type: | Ordinary Product |
| Warranty Of Core Components: | 5 Years | Core Components: | PLC, Motor, Craft |
| Warranty: | 2 Years | Product: | Pass Box |
| Use: | Reduce The Contamination Of Clean Rooms From Small Items | Add-on Features: | Allowed, Please Contact Us |
| Locks: | Electronic Locks | Buzzer,Walkie-talkie: | Supported Options Custom |
| Air Shower,Laminar Flow: | Supported Options Custom | DOP,Barometer: | Supported Options Custom |
| Keyword: | Cleanroom Clean Room Pass Box For | Product Name: | Pass Box For Clean Room |
| Port: | ShenZhen Port, Acording To Customer Requirements | Certification: | ISO,CE,UL,RoHS |
| Highlight: | Cleanroom Stainless Steel Pass Through Cabinet,Customizable Stainless Steel Pass Through Cabinet,Pharma Laminar Flow Pass Box |
||
Product Description
Customizable Cleanroom Stainless Steel Pass Through Cabinet
Customized Electric Pass Box Pass Through Box GMP Pass Box OEM/ODM Acceptable
Specification
| Product | Pass Box |
|---|---|
| Material | Aluminum / Steel / Stainless Steel / Custom |
| Features | Internal arc treatment, seamless connection |
| Add-on Features | Allowed, Please contact us |
| Locks | Mechanical locks / Electronic locks |
| Landing and Lifting | Supported Options Custom |
Product Details
GMP Electronic Interlocking Transfer Window
- Stainless steel door hinge, all stainless steel ball handle
- Tempered glass observation windows, EVA high-performance sealing
- 8cm round steel mechanical interlock or imported electronic interlock
Product Dimensions & Specifications
| Model No. | Outer Size | Inner Size | Material | Weight |
|---|---|---|---|---|
| Mechanical Lock Pass Box | ||||
| 400CS | W 560mm D 480mm H 520mm | W 400mm D 400mm H 400mm | External: Coated Cold Steel Internal: 304 Stainless | 30 kg |
| 400SS | W 560mm D 480mm H 520mm | W 400mm D 400mm H 400mm | All 304 Stainless | 33 kg |
| 600CS | W 760mm D 680mm H 720mm | W 600mm D 600mm H 600mm | External: Coated Cold Steel Internal: 304 Stainless | 45 kg |
| 600SS | W 760mm D 680mm H 720mm | W 600mm D 600mm H 600mm | All 304 Stainless | 50 kg |
| 800CS | W 960mm D 880mm H 920mm | W 800mm D 800mm H 800mm | External: Coated Cold Steel Internal: 304 Stainless | 60 kg |
| 800SS | W 960mm D 880mm H 920mm | W 800mm D 800mm H 800mm | All 304 Stainless | 66 kg |
| Air Shower Pass Box | ||||
| 600FCS | W 950mm D 680mm H 1550mm | W 600mm D 600mm H 600mm | External: Coated Cold Steel Internal: 304 Stainless | 70 kg |
| 600FSS | W 950mm D 680mm H 1550mm | W 600mm D 600mm H 600mm | All 304 Stainless | 89 kg |
| 800FCS | W 1550mm D 880mm H 1750mm | W 800mm D 800mm H 800mm | External: Coated Cold Steel Internal: 304 Stainless | 100 kg |
| 800FSS | W 1550mm D 880mm H 1750mm | W 800mm D 800mm H 800mm | All 304 Stainless | 118 kg |
| 1000FCS | W 1350mm D 1080mm H 1950mm | W 1000mm D 1000mm H 1000mm | External: Coated Cold Steel Internal: 304 Stainless | 130 kg |
| 1000FSS | W 1350mm D 1080mm H 1950mm | W 1000mm D 1000mm H 1000mm | All 304 Stainless | 148 kg |
| Laminar Flow Pass Box | ||||
| 400LCS | W 600mm D 490mm H 1000mm | W 400mm D 400mm H 400mm | External: Coated Cold Steel Internal: 304 Stainless | 59 kg |
| 400LSS | W 600mm D 490mm H 1000mm | W 400mm D 400mm H 400mm | All 304 Stainless | 78 kg |
| 600LCS | W 800mm D 690mm H 1200mm | W 600mm D 600mm H 600mm | External: Coated Cold Steel Internal: 304 Stainless | 83 kg |
| 600LSS | W 800mm D 690mm H 1200mm | W 600mm D 600mm H 600mm | All 304 Stainless | 100 kg |
| 800LCS | W 1100mm D 890mm H 1400mm | W 800mm D 800mm H 800mm | External: Coated Cold Steel Internal: 304 Stainless | 112 kg |
| 800LSS | W 1100mm D 890mm H 1400mm | W 800mm D 800mm H 800mm | All 304 Stainless | 145 kg |
Our Advantages
- Professional manufacturer with 12 years of experience
- 20,000㎡ factory facility
- Leading company in the clean room industry
- More than 300 people including R&D and production teams
- Accept R&D, sampling, production and mass production of non-standard products
- Fast delivery of standard products
- Two years warranty on all products
- Main products include: FFU, air shower room, cargo shower room, clean washbasin, laminar flow hood, clean room, pass box, HEPA filter, etc., providing one-stop solutions
- 24 hours online services
Why Choose Us
Certifications
Frequently Asked Questions
Q1: Do you accept small orders?
A: Yes, we accept small orders or trial orders.
Q2: What is your minimum order requirement?
A: The minimum order required for all our styles is 1 product. Please contact us for details.
Q3: Can you do design for my ideas or drawing?
A: Yes, we have experienced designers. Please send the detailed requirements directly.
Q4: How should I supply my own artwork to you?
A: Most preferred format is PDF or Coreldraw vector artwork and all fonts converted to outlines/curves. We also accept .jpg, .pdf, .tiff, .png, .psd or .bmp files (please enlarge artwork 4 times larger than the pin size).
Q5: Will I receive an art proof before you produce my products?
A: Yes, we will send you a proof after receipt of your order and will not produce until we get your approval of the artwork.
Q6: How long can you ship the goods? Do you have stock for this item?
A: For products that are in stock, we can deliver to you in 1-3 days. Regular lead time for mass production is 20 days depending on order quantity. We keep some stock for standard items but the stock quantity is always floating. Please feel free to contact us to get more updated information.
