Customized Dynamic GMP Electronic Interlocking Clean Room Pass Box for Laboratory Transfer Window
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | MRJH |
| Certification: | ISO 14644,EU GMP,FDA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Packaging Details: | Individually packed,<br>Packed in wooden cases,<br>Packing according to customer's requirement |
| Delivery Time: | 7-15 working days |
| Supply Ability: | 2000 Box/Boxes per Day |
|
Detail Information |
|||
| Features: | Internal Arc Treatment, Seamless Connection | Condition: | New |
|---|---|---|---|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advert | Weight (KG): | 33 |
| Showroom Location: | China | Video Outgoing-inspection: | Support |
| Machinery Test Report: | Support | Marketing Type: | Ordinary Product |
| Warranty Of Core Components: | 5 Years | Core Components: | PLC, Motor, Craft |
| Warranty: | 2 Years | Product: | Pass Box |
| Use: | Reduce The Contamination Of Clean Rooms From Small Items | Add-on Features: | Allowed, Please Contact Us |
| Locks: | Electronic Locks | Buzzer,Walkie-talkie: | Supported Options Custom |
| Air Shower,Laminar Flow: | Supported Options Custom | DOP,Barometer: | Supported Options Custom |
| Keyword: | Cleanroom Clean Room Pass Box | Product Name: | Pass Box For Clean Room |
| Port: | ShenZhen Port, Acording To Customer Requirements | Certification: | ISO,CE,UL,RoHS |
| Highlight: | Laboratory Clean Room Pass Box,Customized Clean Room Pass Box,Biotechnology Dynamic Pass Box |
||
Product Description
Customized Laboratory Clean Room Pass Box Dynamic Pass Box For Biotechnology
Product Overview
Dynamic Pass Box Cleanroom Clean Room Pass Box For Laboratory Cleanroom Clean Room Pass Box For Biotechnology
Our Advantages
- Professional manufacturer with 12 years of experience
- 20,000㎡ factory
- Leading company in the clean room industry
- More than 300 people include R&D and production
- Accept R&D, sampling, production and mass production of non-standard products
- Fast delivery of standard products
- Two years warranty
- Main products including: FFU, air shower room, cargo shower room, clean washbasin, laminar flow hood, clean room, pass box, HEPA filter, etc., providing one-stop solutions
- 24 hours online services
Product Specifications
Customized Electric Pass Box Pass Through Box GMP Pass Box OEM/ODM Acceptable
| Product | Pass Box |
|---|---|
| Material | Aluminum / Steel / SS / Custom |
| Features | Internal arc treatment, seamless connection |
| Add-on Features | Allowed, Please contact us |
| Locks | Mechanical locks / Electronic locks |
| Landing and Lifting | Supported Options Custom |
Product Details
GMP Electronic Interlocking Transfer Window
The GMP (Good Manufacturing Practice) electronic interlocking transfer window is a specialized window system commonly used in pharmaceutical manufacturing facilities or cleanrooms.
Key Features
- Material Transfer: Facilitates transfer of materials between controlled environments while maintaining integrity and cleanliness
- Interlocking Mechanism: Ensures only one side can be accessed at a time to prevent cross-contamination
- GMP Compliance: Meets strict Good Manufacturing Practice guidelines for cleanliness and contamination control
- Airflow and Pressure Control: Maintains appropriate airflow and pressure differentials between connected areas
- Security and Monitoring: Incorporates access control systems and monitoring sensors for authorized use
Technical Specifications Table
| NO. | OUT SIZE | IN SIZE | MATERIAL | WEIGHT |
|---|---|---|---|---|
| Mechanical Lock Pass Box | ||||
| 400CS | W 560 mm D 480 mm H 520 mm | W 400 mm D 400 mm H 400 mm | External: Coated Cold Steel Internal: 304 | 30 kg |
| 400SS | W 560 mm D 480 mm H 520 mm | W 400 mm D 400 mm H 400 mm | All 304 | 33 kg |
| 600CS | W 760 mm D 680 mm H 720 mm | W 600 mm D 600 mm H 600 mm | External: Coated Cold Steel Internal: 304 | 45 kg |
| 600SS | W 760 mm D 680 mm H 720 mm | W 600 mm D 600 mm H 600 mm | All 304 | 50 kg |
| 800CS | W 960 mm D 880 mm H 920 mm | W 800 mm D 800 mm H 800 mm | External: Coated Cold Steel Internal: 304 | 60 kg |
| 800SS | W 960 mm D 880 mm H 920 mm | W 800 mm D 800 mm H 800 mm | All 304 | 66 kg |
| GMP Electronic Lock Pass Box | ||||
| 400GCS | W 600 mm D 490 mm H 560 mm | W 400 mm D 400 mm H 400 mm | External: Coated Cold Steel Internal: 304 | 33 kg |
| 400GSS | W 600 mm D 490 mm H 560 mm | W 400 mm D 400 mm H 400 mm | All 304 | 40 kg |
| 600GCS | W 800 mm D 690 mm H 760 mm | W 600 mm D 600 mm H 600 mm | External: Coated Cold Steel Internal: 304 | 43 kg |
| 600GSS | W 800 mm D 690 mm H 760 mm | W 600 mm D 600 mm H 600 mm | All 304 | 55 kg |
| 800GCS | W 1100 mm D 890 mm H 960 mm | W 800 mm D 800 mm H 800 mm | External: Coated Cold Steel Internal: 304 | 59 kg |
| 800GSS | W 1100 mm D 890 mm H 960 mm | W 800 mm D 800 mm H 800 mm | All 304 | 69 kg |
| Air Shower Pass Box | ||||
| 600FCS | W 950 mm D 680 mm H 1550 mm | W 600 mm D 600 mm H 600 mm | External: Coated Cold Steel Internal: 304 | 70 kg |
| 600FSS | W 950 mm D 680 mm H 1550 mm | W 600 mm D 600 mm H 600 mm | All 304 | 89 kg |
| 800FCS | W 1550 mm D 880 mm H 1750 mm | W 800 mm D 800 mm H 800 mm | External: Coated Cold Steel Internal: 304 | 100 kg |
| 800FSS | W 1550 mm D 880 mm H 1750 mm | W 800 mm D 800 mm H 800 mm | All 304 | 118 kg |
| 1000FCS | W 1350 mm D 1080 mm H 1950 mm | W 1000 mm D 1000 mm H 1000 mm | External: Coated Cold Steel Internal: 304 | 130 kg |
| 1000FSS | W 1350 mm D 1080 mm H 1950 mm | W 1000 mm D 1000 mm H 1000 mm | All 304 | 148 kg |
| Laminar Flow Pass Box | ||||
| 400LCS | W 600 mm D 490 mm H 1000 mm | W 400 mm D 400 mm H 400 mm | External: Coated Cold Steel Internal: 304 | 59 kg |
| 400LCS | W 600 mm D 490 mm H 1000 mm | W 400 mm D 400 mm H 400 mm | All 304 | 78 kg |
| 600LCS | W 800 mm D 690 mm H 1200 mm | W 600 mm D 600 mm H 600 mm | External: Coated Cold Steel Internal: 304 | 83 kg |
| 600LCS | W 800 mm D 690 mm H 1200 mm | W 600 mm D 600 mm H 600 mm | All 304 | 100 kg |
| 800LCS | W 1100 mm D 890 mm H 1400 mm | W 800 mm D 800 mm H 800 mm | External: Coated Cold Steel Internal: 304 | 112 kg |
| 800LCS | W 1100 mm D 890 mm H 1400 mm | W 800 mm D 800 mm H 800 mm | All 304 | 145 kg |
Why Choose Us
Buyer Evaluation
Certifications
Frequently Asked Questions
Q1: Do you accept small orders?
A: Yes, we accept small orders or trial orders.
Q2: What is your minimum order requirement?
A: The minimum order required for all our styles is 1 product. Please contact us for details.
Q3: Can you do design for my ideas or drawing?
A: Yes, we have experienced designers. Please send the detailed requirements directly.
Q4: How should I supply my own artwork to you?
A: Most preferred format is PDF or Coreldraw vector artwork and all fonts converted to outlines/curves. We also accept .jpg, .pdf, .tiff, .png, .psd or .bmp files (please enlarge artwork 4 times larger than the pin size).
Q5: Will I receive an art proof before you produce my products?
A: Yes, we will send you a proof after receipt of your order and will not produce until we get your approval of the artwork.
Q6: How long can you ship the goods? Do you have stock for this item?
A: For products that are in stock, we can deliver to you in 1-3 days. Regular lead time for mass production is 20 days depending on order quantity. We keep some stock for standard items but the stock quantity is always floating. Please feel free to contact us to get more update info.
Q7: What if I need to make changes or cancel my order after it's in production?
A: Any changes or cancellations are subject to charges based on costs incurred up to time of your request. No change is accepted once an order is in production. It will be processed as a new order.
Q8: How about the after-sales service?
A: We do 100% inspection during production and before packaging. If there is any problem with quality, we'd like to provide a replacement in the next order. Please contact us directly below without hesitate, your inquiry will be answered promptly.
