Lab Clean Room Pass Box with Internal Arc Treatment and Seamless Connection for Static Dynamic Air Shower
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | MRJH |
| Certification: | ISO 14644,EU GMP,FDA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Packaging Details: | Individually packed,<br>Packed in wooden cases,<br>Packing according to customer's requirement |
| Delivery Time: | 7-15 working days |
| Supply Ability: | 300 Set/Sets per Week |
|
Detail Information |
|||
| Features: | Internal Arc Treatment, Seamless Connection | Condition: | New |
|---|---|---|---|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advert | Weight (KG): | 55 |
| Showroom Location: | None | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | Ordinary Product |
| Warranty Of Core Components: | 5 Years | Core Components: | Motor |
| Warranty: | 2 Years | Product: | Pass Box |
| Material: | Aluminum / Steel / SS. / Custom | Use: | Reduce The Contamination Of Clean Rooms From Small Items |
| Add-on Features: | Allowed, Please Contact Us | Locks: | Mechanical Locks / Electronic Locks |
| Buzzer,Walkie-talkie: | Supported Options Custom | Air Shower,Laminar Flow: | Supported Options Custom |
| DOP,Barometer: | Supported Options Custom | Landing And Lifting: | Supported Options Custom |
| Port: | ShenZhen Port, Acording To Customer Requirements | Certification: | ISO,CE,UL,RoHS |
| Highlight: | Lab Clean Room Pass Box,Static Clean Room Pass Box,Dynamic Air Shower Pass Box |
||
Product Description
Lab Clean Room Pass Box - Static & Dynamic Air Shower Pass Box
Product Overview
Our clean room pass box is specifically designed for laboratory applications, featuring double door air shower technology with internal arc treatment and seamless connections. Customized OEM/ODM solutions are available to meet your specific requirements.
Key Specifications
- Product: Pass Box
- Material: Aluminum / Steel / Stainless Steel / Custom
- Primary Use: Reduce contamination of clean rooms during small item transfers
- Applications: Medical, Pharmacy, Food Industry, Livestock, Power Plants, Healthcare, Hospitals, Research Institutions, Aerospace Technology, Auto Industry
Standard Features
- Internal arc treatment for smooth surface finish
- Seamless connection design
- Mechanical interlocking system
- Customizable options available
Optional Features
- Buzzer and walkie-talkie systems
- Air shower and laminar flow systems
- DOP testing and barometer integration
- Landing and lifting mechanisms
Cold Paint Plate Pass Box
Specialized pass box designed for automotive and manufacturing industries to handle freshly painted plates and panels with precise temperature control and contamination prevention.
Key Features
- Material Transfer: Specifically designed for painted plates and panels
- Temperature Control: Maintains optimal temperature for paint curing
- Contamination Prevention: HEPA filtration systems protect paint finish
GMP Electronic Interlocking Transfer Window
- Stainless steel door hinge and handle
- Tempered glass observation windows
- EVA high-performance sealing
- 8cm round steel mechanical interlock or imported electronic interlock
Application Examples
Technical Specifications
Mechanical Lock Pass Box
| Model | Outer Size | Inner Size | Material | Weight |
|---|---|---|---|---|
| 400CS | W 560mm D 480mm H 520mm | W 400mm D 400mm H 400mm | External: Coated Cold Steel Internal: 304 Stainless |
30 kg |
| 400SS | W 560mm D 480mm H 520mm | W 400mm D 400mm H 400mm | All 304 Stainless Steel | 33 kg |
| 600CS | W 760mm D 680mm H 720mm | W 600mm D 600mm H 600mm | External: Coated Cold Steel Internal: 304 Stainless |
45 kg |
| 600SS | W 760mm D 680mm H 720mm | W 600mm D 600mm H 600mm | All 304 Stainless Steel | 50 kg |
| 800CS | W 960mm D 880mm H 920mm | W 800mm D 800mm H 800mm | External: Coated Cold Steel Internal: 304 Stainless |
60 kg |
| 800SS | W 960mm D 880mm H 920mm | W 800mm D 800mm H 800mm | All 304 Stainless Steel | 66 kg |
GMP Electronic Lock Pass Box
| Model | Outer Size | Inner Size | Material | Weight |
|---|---|---|---|---|
| 400GCS | W 600mm D 490mm H 560mm | W 400mm D 400mm H 400mm | External: Coated Cold Steel Internal: 304 Stainless |
33 kg |
| 400GSS | W 600mm D 490mm H 560mm | W 400mm D 400mm H 400mm | All 304 Stainless Steel | 40 kg |
| 600GCS | W 800mm D 690mm H 760mm | W 600mm D 600mm H 600mm | External: Coated Cold Steel Internal: 304 Stainless |
43 kg |
| 600GSS | W 800mm D 690mm H 760mm | W 600mm D 600mm H 600mm | All 304 Stainless Steel | 55 kg |
| 800GCS | W 1100mm D 890mm H 960mm | W 800mm D 800mm H 800mm | External: Coated Cold Steel Internal: 304 Stainless |
59 kg |
| 800GSS | W 1100mm D 890mm H 960mm | W 800mm D 800mm H 800mm | All 304 Stainless Steel | 69 kg |
Air Shower Pass Box
| Model | Outer Size | Inner Size | Material | Weight |
|---|---|---|---|---|
| 600FCS | W 950mm D 680mm H 1550mm | W 600mm D 600mm H 600mm | External: Coated Cold Steel Internal: 304 Stainless |
70 kg |
| 600FSS | W 950mm D 680mm H 1550mm | W 600mm D 600mm H 600mm | All 304 Stainless Steel | 89 kg |
| 800FCS | W 1550mm D 880mm H 1750mm | W 800mm D 800mm H 800mm | External: Coated Cold Steel Internal: 304 Stainless |
100 kg |
| 800FSS | W 1550mm D 880mm H 1750mm | W 800mm D 800mm H 800mm | All 304 Stainless Steel | 118 kg |
| 1000FCS | W 1350mm D 1080mm H 1950mm | W 1000mm D 1000mm H 1000mm | External: Coated Cold Steel Internal: 304 Stainless |
130 kg |
| 1000FSS | W 1350mm D 1080mm H 1950mm | W 1000mm D 1000mm H 1000mm | All 304 Stainless Steel | 148 kg |
Laminar Flow Pass Box
| Model | Outer Size | Inner Size | Material | Weight |
|---|---|---|---|---|
| 400LCS | W 600mm D 490mm H 1000mm | W 400mm D 400mm H 400mm | External: Coated Cold Steel Internal: 304 Stainless |
59 kg |
| 400LSS | W 600mm D 490mm H 1000mm | W 400mm D 400mm H 400mm | All 304 Stainless Steel | 78 kg |
| 600LCS | W 800mm D 690mm H 1200mm | W 600mm D 600mm H 600mm | External: Coated Cold Steel Internal: 304 Stainless |
83 kg |
| 600LSS | W 800mm D 690mm H 1200mm | W 600mm D 600mm H 600mm | All 304 Stainless Steel | 100 kg |
| 800LCS | W 1100mm D 890mm H 1400mm | W 800mm D 800mm H 800mm | External: Coated Cold Steel Internal: 304 Stainless |
112 kg |
| 800LSS | W 1100mm D 890mm H 1400mm | W 800mm D 800mm H 800mm | All 304 Stainless Steel | 145 kg |
Need Assistance With Your Selection?
Contact our customer service team for direct access to the perfect product for your requirements!
Company Advantages
About Our Company
Shenzhen Meiri Purification Technology Co., Ltd
Founded in 2012, we specialize in research, development, sales, and service of air filters, air purification equipment, and clean room solutions.
Manufacturing Capabilities
- Clean production hall with advanced air filtration
- 2 AMADA automatic CNC presses
- 5 automatic CNC bending machines
- 5 shearing machines and multiple bending machines
- 2 interactive laser engraving machines
- Dozens of national patents and international certifications (CE, UL, ROHS, REACH)
Production Equipment
Quality Testing Equipment
Shipping & Logistics
Transportation: Shipping options available by sea or air
Packaging: Bulk or customized packaging according to customer requirements
Certifications & Quality Standards
Our modern quality management system complies with international standards including ISO9001 and ISO14001. All certificates can be verified, and we welcome factory visits for inspection.
Frequently Asked Questions
Q: What's your sample and production lead time?
A: Sample lead time: 3-7 days. Mass production: 2-3 weeks.
Q: How do you ship the goods?
A: Full containers: vessel shipping. Small/urgent orders: air freight or international couriers.
Q: Where is your company located?
A: No. 79, Langbei Village Industry Road, Tongde Community, Baolong Street, Longgang District, Shenzhen City, Guangdong Province, China.
Q: Can you arrange a visit to your factory?
A: Yes, of course.
Q: Can you provide customized products as per our requirements?
A: Yes, of course.
Q: Do you test all your products before delivery?
A: Yes, we perform 100% testing and provide test reports before delivery.
Q: How long is your delivery time?
A: Typically 10-30 days, depending on order size, quantity, and configuration.
Q: What payment terms do you accept?
A: T/T, L/C, etc. Price terms: EXW, FOB, CFR, CIF, DDU, etc.
Q: What after-sales service do you provide?
A: 24-hour technical support via email, phone, video, etc.
Q: How many countries have you exported to?
A: Over 30 countries across Asia, Middle East, Africa, Europe, North America, and South America.
