ISO 5 Clean Booth with HEPA FFU System | Modular & Mobile Design for Labs/Electronics
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | MRJH |
| Certification: | ISO 14644,GMP |
| Model Number: | Class 100 clean room 2500 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Delivery Time: | 7-15 days |
|
Detail Information |
|||
| Size: | W2500 × D2800 × H2200 (mm) | Custom Made: | Support |
|---|---|---|---|
| Class: | 100~ 300000 | ISO: | ISO5~ISO9 Or Customized |
| Official Website: | Www.ffu-cleanroom.com | ||
| Highlight: | HEPA FFU Clean Booth,Mobile Clean Booth,Modular Clean Booth |
||
Product Description
ISO 5 Clean Booth with HEPA FFU System | Modular & Mobile Design for Labs/Electronics
The Clean Booth is designed to maintain ISO Class 5 (Class 100) air quality for contamination-sensitive processes, compliant with ISO 14644-1 standards. Constructed with a galvanized aluminum frame and sealed with transparent mesh curtains, it is ideal for electronics manufacturing, pharmaceutical cleanrooms, and precision laboratories. Equipped with 7 non-partitioned HEPA filters (1170×570×69), low-noise FFUs, and integrated clean lighting, it ensures stable airflow, minimal vibration, and efficient particle control.
|
Parameter Name |
Value |
|
Material |
Galvanized aluminum frame, sealed with transparent mesh curtains |
|
Internal Design |
Clean lighting, distribution box |
|
Filtration System |
7× FFU (1175×575×285 aluminum frame HEPA filters) |
|
Control System |
Distribution box for power management |
|
Airflow & Noise |
Noise: 48–58 dB ±5dB; Rated power: 150–190W ±5W; Vibration: <5µm |
|
Fan & Filtration |
HEPA filtration efficiency ≥99.995% @ 0.3µm |
|
Lighting |
Integrated clean LED lights |
|
External Dimensions |
W2500 × D2800 × H2200 (mm) |
|
Certifications |
ISO 9001 |
Key Features
1. Galvanized Aluminum Construction: Durable frame with transparent mesh curtains for visibility and contamination control.
2. High-Efficiency Filtration: 7× FFUs with non-partitioned HEPA filters (99.995% @ 0.3µm) ensure ISO Class 5 compliance.
3. Low-Noise Operation: Optimized airflow design with noise levels of 48–58 dB and vibration <5µm.
4. Integrated Lighting: Clean LED lights for uniform illumination during operations.
5. Stable Power Supply: 220V/50Hz distribution box for reliable FFU and lighting operation.
6. Modular Design: Easy installation and maintenance with standardized components.
Application Scenarios
Electronics Manufacturing: Contamination-free assembly of sensitive components.
Pharmaceutical Cleanrooms: Material handling and processing in ISO Class 5 environments.
Biotechnology Labs: Sterile sample preparation and testing.
FAQ 1: How does the ISO 5 Clean Booth ensure compliance with pharmaceutical/electronics industry standards?
A:This clean booth meets ISO 14644-1 Class 5 requirements using 7× HEPA FFUs (99.995% efficiency @ 0.3µm) and controlled airflow (48–58 dB noise). The galvanized aluminum frame and anti-static mesh curtains prevent contamination, making it ideal for FDA-compliant pharma labs or ESD-sensitive electronics assembly.
FAQ 2: Can the modular design adapt to small lab spaces or high-volume production areas?
A:Yes, its modular aluminum frame allows flexible sizing (standard: 2500W×2800D×2200H mm) and quick reconfiguration. The mobile base supports relocation without disassembly, ideal for tight R&D labs or scalable electronics manufacturing lines.
FAQ 3: Does the HEPA FFU system require frequent maintenance, and what’s the energy cost?
A:The low-maintenance FFUs operate at 150–190W with vibration <5µm, reducing filter wear. HEPA replacements are typically annual under normal use. Energy costs are 30% lower than traditional cleanrooms due to localized airflow control.
